Cooling Fans Reviews

EKL Alpenföhn Wing Boost 3 ARGB High Speed White Edition Review – When data sheet and reality collide

Disclaimer: The following article is machine translated from the original German, and has not been edited or checked for errors. Thank you for understanding!

With the Alpenföhn Wing Boost 3 ARGB High Speed, EKL expands its own portfolio with a bright 120 mm case fan, which is available in black and white. You can either buy it separately or as a triple pack with RGB controller and remote control. But since we don’t want to evaluate the colorful appearance, but the performance, we naturally focus on the individual piece. After we had already tested the unlit Wing Boost 3 as a 140 mm variant some time ago and various questions remained unanswered, it will be interesting to see how the obviously also once again revised 120 mm model performs.

The fan tested today was sent to us by the manufacturer’s marketing department (unfortunately loose and without packaging) as part of the post-processing of the last test, so that the same is missing from the picture gallery of the fan. Here I ask for your indulgence and we can only hope that the sample sent to us is really normal retail goods. But after a closer look at the fan, we assume that this is probably the case, otherwise we wouldn’t have done the test either. Nevertheless, in the conclusion I will still have to address why fanciful data sheet claims should not be used to mislead customers.

The bearing is a classic FDB (Fluid-Dynamic Bearing) design, a white, slightly more torsion-resistant frame and an 11-blade rotor with an asymmetrical blade geometry that doesn’t hide any secrets at first glance. Compared to older models, the impeller seems a bit more massive, which in combination with the different frame could have eliminated the annoying humming of the older models. ARGB is of course also available with this fan, whereby the LEDs are not located in the hub, but in the static frame. The PWM-controlled fan manages a speed range from 500 to 2200 rpm and does without a semi-passive mode (with fan stop), but relies on a permanent minimum speed.

The decoupling with the comprehensively attached rubber applications is neatly solved, as it does not twist with the screw tightened. The gap dimensions and surface finish are good. The power consumption turns out to be quite steep with more than 4 watts at full speed. It a light disc on the market more, which is now to be tested intensively. But first of all once again the key data for better comparability to the later measurement results:

Form factor 120 mm
Starch 25 mm
PWM Yes
RGB ARGB (Frame)
Decoupled Yes
Color Frame White
Accent color none
Color rotor White
Weight in g 208.6
min. speed 500 (no fan stop)
max. speed 2200
Volume flow m3/h 132,4
Flow rate CFM 77.92
static pressure mmH2O 3.24
Sound pressure dBA 36.8
Life Time hrs 250,000

On the next page you will first see how and what we test and why. Understanding the details is extremely important in order to be able to objectively classify the results later. The differences between many models are more in the details and THE best fan for all situations can hardly exist. There is a certain optimum in every situation and of course there are also good all-rounders. But they usually have their price. But if you plan to use 60mm radiators for example, you might save money by choosing the best model for your application, which might not perform so well as a case fan. And vise versa, of course.

For all curious people here again an excerpt of the data sheet, whereby I compressed the original (without optical loss) a little bit. You don’t have to come up with over 6 MB for four simple pages to anyone these days, especially when it eats up your mobile data allowance. This is a hint for the webmaster, who could have noticed that.

WingBoost 3 ARBG 120mm

Alpenföhn Wing Boost 3 ARGB High Speed White Edition, weiß, 120mm (84000000166)

MindfactoryZentrallager: verfügbar, Lieferung 3-5 WerktageFiliale Wilhelmshaven: nicht lagerndStand: 27.11.21 14:4519,36 €*Stand: 27.11.21 14:39
equipprAuf Lager, 1-3 Werktage Lieferzeit19,40 €*Stand: 27.11.21 14:52
HardwareRatLagernd19,48 €*Stand: 27.11.21 14:06
*Alle Preise inkl. gesetzl. MwSt zzgl. Versandkosten und ggf. Nachnahmegebühren, wenn nicht anders beschriebenmit freundlicher Unterstützung von www.geizhals.de
